Self extinguishing and no drips according to ASTM D635-91.
Rubber foam is your smart choice for energy saving, with low thermal conductivity ≤0.034 W/m.K.
No dust and fiber, CFC free, Low VOCs, No fungal growth, Negligible bacterial growth.
Due to rubber foam high flexible performance, it is easy to bend and irregular pipes, cut into different shapes and sizes and can save labor and materials.
Can custom various colors such as red, blue, green, grey, yellow, grey and so on. Your finished piping lines will be much nicer and it is easy to distinguish different pipes inside for maintaining.
| Technical Data | |||
|---|---|---|---|
| Property | Unit | Value | Test Method |
| Temperature range | °C | (-50 - 110) | GB/T 17794-1999 |
| Density range | Kg/m³ | 45-65Kg/m³ | ASTM D1667 |
| Water vapor permeability | Kg/(m.s.pa) | ≤0.91×10⁻¹³ | DIN 52 615 / BS 4370 Part 2 1973 |
| μ | - | ≥10000 | |
| Thermal Conductivity | W/(m.k) | ≤0.030 (-20°C) | ASTM C 518 |
| ≤0.032 (0°C) | |||
| ≤0.036 (40°C) | |||
| Fire Rating | - | Class 0 & Class 1 | BS 476 Part 6 part 7 |
| Flame Spread and Smoke Developed Index | - | 25/50 | ASTM E 84 |
| Oxygen Index | - | ≥36 | GB/T 2406,ISO4589 |
| Water Absorption,% by Volume | % | 20% | ASTM C 209 |
| Dimension Stability | - | ≤5 | ASTM C534 |
| Fungi resistance | - | Good | ASTM 21 |
| Ozone resistance | Good | GB/T 7762-1987 | |
| Resistance to U.V. and weather | Good | ASTM G23 | |
Rubber foam Material is soft heat-insulating, heat-preservation and energy conservation materials made with advanced technology at home and advanced full-automatic continuous production line imported from abroad, using butyronitrile rubber with best performance and polyvinyl Chloride (NBR,PVC) as main raw materials and other high quality auxiliary materials through foaming and so on special procedure.
| Dimension Specifications | |||||||
|---|---|---|---|---|---|---|---|
| Thickness | Width 1m | Width 1.2m | Width 1.5m | ||||
| Inches | mm | Size (L*W) | ㎡/Roll | Size (L*W) | ㎡/Roll | Size (L*W) | ㎡/Roll |
| 1/4" | 6 | 30 × 1 | 30 | 30 × 1.2 | 36 | 30 × 1.5 | 45 |
| 3/8" | 10 | 20 × 1 | 20 | 20 × 1.2 | 24 | 20 × 1.5 | 30 |
| 1/2" | 13 | 15 × 1 | 15 | 15 × 1.2 | 18 | 15 × 1.5 | 22.5 |
| 3/4" | 19 | 10 × 1 | 10 | 10 × 1.2 | 12 | 10 × 1.5 | 15 |
| 1" | 25 | 8 × 1 | 8 | 8 × 1.2 | 9.6 | 8 × 1.5 | 12 |
| 1 1/4" | 32 | 6 × 1 | 6 | 6 × 1.2 | 7.2 | 6 × 1.5 | 9 |
| 1 1/2" | 40 | 5 × 1 | 5 | 5 × 1.2 | 6 | 5 × 1.5 | 7.5 |
| 2" | 50 | 4 × 1 | 4 | 4 × 1.2 | 4.8 | 4 × 1.5 | 6 |
It features excellent fire performance and is self-extinguishing with no drips according to ASTM D635-91. It meets Class 0 and Class 1 standards according to BS 476 Part 6 & 7.
The material is CFC-free, has low VOC emissions, produces no dust or fibers, and successfully resists both fungal and bacterial growth.
Yes, due to its highly flexible nature, the rubber foam can easily bend around irregular pipes and be cut into different shapes and sizes, which saves both labor and materials.
It has a low thermal conductivity rating of ≤0.034 W/m.K, making it a highly energy-efficient solution for various piping applications.
Yes, custom colors such as red, blue, green, grey, yellow, and others are available to make piping identification and maintenance much simpler.
It is manufactured using high-performance butyronitrile rubber and polyvinyl chloride (NBR/PVC) as the primary raw materials, processed via advanced continuous foaming technology.
