| Technical Data Sheet | |||
|---|---|---|---|
| Property | Unit | Value | Test Method |
| Temperature range | °C | (-50 - 110) | GB/T 17794-1999 |
| Density range | Kg/m³ | 45-65Kg/m³ | ASTM D1667 |
| Water vapor permeability | Kg/(m.s.pa) | ≤0.91×10⁻¹³ | DIN 52 615 BS 4370 Part 2 1973 |
| μ | - | ≥10000 | - |
| Thermal Conductivity | W/(m.k) | ≤0.030 (-20°C) | ASTM C 518 |
| ≤0.032 (0°C) | |||
| ≤0.036 (40°C) | |||
| Fire Rating | - | Class 0 & Class 1 | BS 476 Part 6 part 7 |
| Flame Spread and Smoke Developed Index | - | 25/50 | ASTM E 84 |
| Oxygen Index | - | ≥36 | GB/T 2406, ISO4589 |
| Water Absorption, %by Volume | % | 20% | ASTM C 209 |
| Dimension Stability | - | ≤5 | ASTM C534 |
| Fungi resistance | - | Good | ASTM 21 |
| Ozone resistance | Good | GB/T 7762-1987 | |
| Resistance to U.V. and weather | Good | ASTM G23 | |
The high density and closed structure of selected raw material has the ability of low thermal conductivity and stable temperature and has an isolation effect of hot and cold medium.
When burned by fire, the insulation material do not melt and resulting in low smoke and do not make the flame spread which can guarantee the using safety; the material is determined as nonflammable material and the range of Using temperature is from -50℃ to 110℃.
The environmental friendly raw material has no stimulation and pollution, no hazard to health and environment. Moreover, it can avoid the mold growth and mouse biting; The material has the effection of corrosion-resistant, acid and alkali, it can increase the life of using.
It is convenient to install due to it is not need to install other auxiliary layer and it is just cutting and conglutinating. It will save the manual work greatly.
The material is highly stable and accommodates a broad temperature range from -50°C to 110°C, making it suitable for both cold and hot media isolation.
The material exhibits excellent low thermal conductivity. Tested under ASTM C 518, it maintains values of ≤0.030 W/(m.k) at -20°C, ≤0.032 W/(m.k) at 0°C, and ≤0.036 W/(m.k) at 40°C.
It meets Class 0 and Class 1 Fire Ratings under BS 476 Part 6 & 7. Additionally, it achieves a 25/50 Flame Spread and Smoke Developed Index (ASTM E 84) and an Oxygen Index of ≥36 (GB/T 2406, ISO4589), ensuring high fire safety without melting.
Yes. The material possesses good resistance properties against ozone (GB/T 7762-1987), UV and general weather degradation (ASTM G23), and fungi growth (ASTM 21), ensuring long-term durability.
Absolutely. It is manufactured using eco-friendly raw materials without hazards to health or the environment. It is non-polluting, prevents mold growth, resists rodent activity, and is highly resistant to acid, alkali, and corrosion.
No, the installation is straightforward. There is no need for extra auxiliary layers. The material can simply be cut to size and conglutinated, significantly reducing installation time and manual work.
