This kind of insulation tube / pipe is made by NBR/PVC with excellent performance as its main raw material. Served with varied subsidiary materials of high quality, the tube foam is made by special craft foam and feels very soft. We can supply rubber foam products according to clients' specific requirements in terms of shapes, colors, hardness levels and other features.
| Technical Data | |||
|---|---|---|---|
| Property | Unit | Value | Test Method |
| Temperature range | °C | (-50 - 110) | GB/T 17794-1999 |
| Density range | Kg/m3 | 45-65Kg/m3 | ASTM D1667 |
| Water vapor permeability | Kg/(m.s.pa) | ≤0.91×10 ﹣¹³ | DIN 52 615 / BS 4370 Part 2 1973 |
| μ | - | ≥10000 | - |
| Thermal Conductivity | W/(m.k) | ≤0.030 (-20°C) | ASTM C 518 |
| ≤0.032 (0°C) | |||
| ≤0.036 (40°C) | |||
| Fire Rating | - | Class 0 & Class 1 | BS 476 Part 6 part 7 |
| Flame Spread and Smoke Developed Index | - | 25/50 | ASTM E 84 |
| Oxygen Index | - | ≥36 | GB/T 2406, ISO4589 |
| Water Absorption,% by Volume | % | 20% | ASTM C 209 |
| Dimension Stability | - | ≤5 | ASTM C534 |
| Fungi resistance | - | Good | ASTM 21 |
| Ozone resistance | - | Good | GB/T 7762-1987 |
| Resistance to U.V. and weather | - | Good | ASTM G23 |
The high density and closed structure of selected raw material has the ability of low thermal conductivity and stable temperature and has an isolation effect of hot and cold medium.
When burned by fire, the insulation material do not melt and resulting in low smoke and do not make the flame spread which can guarantee the using safety; the material is determined as nonflammable material and the range of Using temperature is from -50℃ to 110℃.
The environmental friendly raw material has no stimulation and pollution, no hazard to health and environment. Moreover, it can avoid the mold growth and mouse biting; The material has the effection of corrosion-resistant, acid and alkali, it can increase the life of using.
It is convenient to install due to it is not need to install other auxiliary layer and it is just cutting and conglutinating. It will save the manual work greatly.
The insulation tubes are manufactured using high-quality NBR (Nitrile Butadiene Rubber) and PVC (Polyvinyl Chloride) as the main raw materials, processed through a special foaming process.
This insulation material is highly resistant and is rated for a safe operating temperature range of -50°C to 110°C.
The material exhibits excellent flame retardant properties. It is classified under BS 476 Part 6 & 7 (Class 0 & Class 1), meaning it does not melt easily, produces low smoke, and prevents flame spread.
Yes, it has good resistance to UV rays, ozone, weather, fungi, acids, and alkalis, making it highly durable for various environments.
Installation is simple and efficient. It does not require additional auxiliary layers and can be easily cut and conglutinated to suit your specific pipe designs.
