China Flexible cryogenic insulation Manufacturer, Quotes

The ultra-low temperature protection system of diolefin and butadiene rubber is a high-performance elastic foaming developed by us specifically for the insulation project under ultra-low temperature conditions.Reducing temperature variation stress is one of the important features of the system over traditional rigid foam insulation materials such as foam glass, polyurethane PIR and PUR.

Product Description

Insulation Material Detail
Insulation Application
Low Temperature Testing
Insulation Material Structure
Flexible Foam Performance

The flexible ultra-low temperature insulation system does not require a moisture barrier. Thanks to the unique closed cell structure and polymer mix formula, the elastic foam material of nitrile butadiene rubber has a high resistance to water vapor penetration. This foam material provides continuous resistance to moisture penetration throughout the thickness of the product.

Closed Cell Structure Detail
Insulation Pipe System
Insulation Layer Fitment
Material Cross Section
ULT Technical Data
Property Unit Value
Temperature range °C (-200 - +110)
Density range Kg/m³ 60-80Kg/m³
Thermal Conductivity W/(m.k) ≤0.028 (-100°C)
≤0.021 (-165°C)
Fungi resistance - Good
Ozone resistance - Good
Resistance to U.V. and weather - Good

Growth in the construction industry and many other industrial segments, combined with concerns over rising energy costs and noise pollution, is fueling market demand for thermal insulation. With more than four decades of dedicated experience in manufacturing and applications, the industry leader is riding on top of the wave.

Industrial Insulation Project
Factory Pipeline Insulation
Low Temp Valve Insulation
Product Strengths & Specifications

With 5 large automatic assembly lines and more than 600,000 cubic meters of annual production capacity, the production enterprise is designated for thermal insulation materials by the National energy department, Ministry of electric power, and Ministry of Chemical industry.

  • No built-in moisture barrier is required
  • No built-in expansion joint
  • The temperature ranges from -200℃ to +125℃
  • It remains elastic at extremely low temperatures
Primary Applications
  • Coal chemical MOT
  • Low temperature storage tank
  • FPSO floating production storage oil unloading device
  • Industrial gas and agricultural chemical production plants
  • Platform pipe
  • Gas station
  • Ethylene pipe
  • LNG
  • Nitrogen plant

Frequently Asked Questions

Does this ultra-low temperature insulation system require an external moisture barrier?
No, a built-in moisture barrier is not required. Thanks to its unique closed cell structure and specialized polymer mix formula, the elastic foam material provides continuous, integrated resistance to moisture and water vapor penetration throughout its thickness.
What is the operating temperature range of this insulation material?
The material is engineered to handle extreme conditions, operating effectively in a wide temperature range from -200℃ up to +125℃. It maintains its elasticity and structural integrity even at extremely low cryogenic temperatures.
What is the thermal conductivity performance at low temperatures?
The insulation offers exceptional thermal performance. Technical testing records a thermal conductivity of ≤0.028 W/(m.k) at -100°C and ≤0.021 W/(m.k) at -165°C.
Does the insulation require built-in expansion joints?
No, the flexible and elastic nature of the nitrile butadiene rubber material eliminates the need for built-in expansion joints, simplifying installation and reducing potential failure points.
Is this insulation material resistant to environmental factors like fungi or UV?
Yes, the system possesses good resistance to fungi growth, ozone, U.V. rays, and overall weather exposure, ensuring long-term durability and safety in diverse outdoor and industrial environments.
