Wholesale Closed Cell Rubber Foam Insulation For the Cryogenic Equipment Systems Supplier, Quotes
Multi-layer composite structure: ULT (Blue) for inner layer; LT (Black) for outer layer.
Main material: ULT—alkadiene polymer; color in Blue
LT—NBR/PVC; color in Black.
Insulation that maintains its flexibility at very low temperatures down to -200℃ to +125℃.
Reduces the risk of corrosion under insulation.
Protects against mechanical impact and shock.
Low thermal conductivity.
Low glass transition temperature.
Easy installation even for complex shapes.
Kingflex Cryogenic Rubber Foam is highly durable and resistant to wear and tear. It is resistant to moisture, chemicals, and UV radiation, making it suitable for use in both indoor and outdoor environments.
Kingflex Dimension
Inches
mm
Size (L*W)
㎡/Roll
3/4"
20
10 × 1
10
1"
25
8 × 1
8
Main Property
Base material
Standard / Test Method
Kingflex ULT
Kingflex LT
Thermal Conductivity
-100°C: 0.028 -165°C: 0.021
0°C: 0.033 -50°C: 0.028
ASTM C177
Density Range
60-80Kg/m³
40-60Kg/m³
ASTM D1622
Recommend Operation Temperature
-200°C to 125°C
-50°C to 105°C
-
Percentage Of Close Areas
>95%
>95%
ASTM D2856
Moisture Performance Factor
NA
<1.96x10g(m.m.Pa)
ASTM E 96
Wet resistance Factor μ
NA
>10000
EN12086 / EN13469
Water Vapor Permeability Coefficient
NA
0.0039g/h.m² (25mm thickness)
ASTM E 96
PH
≥8.0
≥8.0
ASTM C871
Tensile Strength Mpa
-100°C: 0.30 -165°C: 0.25
0°C: 0.15 -50°C: 0.218
ASTM D1623
Compressive Strength Mpa
-100°C: ≤0.3
-40°C: ≤0.16
ASTM D1621
Frequently Asked Questions
What is the operating temperature range for Cryogenic Rubber Foam?
The insulation material maintains its excellent flexibility at very low temperatures down to -200℃ and can handle temperatures up to +125℃.
How does this insulation prevent Corrosion Under Insulation (CUI)?
By offering high resistance to moisture and chemicals alongside a high close-cell percentage (>95%), it effectively keeps moisture away from the pipe surface, reducing the risk of corrosion.
Can this material be installed on complex industrial shapes?
Yes. Due to its high flexibility and low glass transition temperature, it is designed for easy installation even on highly complex shapes and piping configurations.
Is the Cryogenic Rubber Foam suitable for outdoor applications?
Yes, the material is formulated to resist UV radiation, moisture, and various chemicals, making it highly durable for both indoor and outdoor environments.
What is the difference between the ULT and LT base materials?
Kingflex ULT is optimized for ultra-low temperatures (-200°C to 125°C) with a density of 60-80Kg/m³, whereas Kingflex LT is suitable for low-temperature applications (-50°C to 105°C) with a density of 40-60Kg/m³.
