| Kingflex Dimension | |||
|---|---|---|---|
| Inches | mm | Size (L * W) | ㎡ / Roll |
| 3/4" | 20 | 10 × 1 | 10 |
| 1" | 25 | 8 × 1 | 8 |
| Main Property | Base material | Test Method / Standard | |
|---|---|---|---|
| Kingflex ULT | Kingflex LT | ||
| Thermal Conductivity | -100°C, 0.028 -165°C, 0.021 |
0°C, 0.033 -50°C, 0.028 |
ASTM C177 |
| Density Range | 60-80 Kg/m³ | 40-60 Kg/m³ | ASTM D1622 |
| Recommend Operation Temperature | -200°C to 125°C | -50°C to 105°C | - |
| Percentage Of Close Areas | >95% | >95% | ASTM D2856 |
| Moisture Performance Factor | NA | <1.96x10g(m.m.Pa) | ASTM E 96 |
| Wet resistance Factor μ | NA | >10000 | EN12086 EN13469 |
| Water Vapor Permeability Coefficient | NA | 0.0039g/h.m² (25mm thickness) |
ASTM E 96 |
| PH | ≥8.0 | ≥8.0 | ASTM C871 |
| Tensile Strength Mpa | -100°C, 0.30 -165°C, 0.25 |
0°C, 0.15 -50°C, 0.218 |
ASTM D1623 |
| Compressive Strength Mpa | -100°C, ≤0.3 | -40°C, ≤0.16 | ASTM D1621 |
Kingflex ULT maintains its flexibility at extremely low temperatures ranging from -200°C to +125°C, while Kingflex LT is recommended for temperatures from -50°C to +105°C.
It features a close area percentage of over 95%, making it highly resistant to moisture, chemicals, and UV radiation. This allows it to perform reliably in both indoor and outdoor environments.
Standard dimensions include a thickness of 3/4" (20mm) with roll sizes of 10m x 1m (10㎡/roll), and 1" (25mm) thickness with roll sizes of 8m x 1m (8㎡/roll).
According to ASTM D1622 test standards, Kingflex ULT has a density range of 60-80 Kg/m³, whereas Kingflex LT has a density range of 40-60 Kg/m³.
Based on ASTM C177 testing, Kingflex ULT achieves a thermal conductivity of 0.021 at -165°C, and Kingflex LT achieves 0.028 at -50°C, ensuring high thermal efficiency.
The manufacturing facility utilizes 5 large automatic assembly lines, delivering an annual production capacity of more than 600,000 cubic meters.
